| GENERAL INFORMATION |
| pitch |
10,16 mm |
| Height |
10.6 mm |
| Depth |
8.1 mm |
| Dimensional class |
Bassa |
| Wire section |
1.5 mm² / 16 AWG |
| Clamp opening size |
2.6 x 2 mm |
| Wire stripping |
max 6 mm |
| Operating temperature |
-40 ÷ +130 °C |
| ELECTRICAL CHARACTERISTICS |
| Current |
13.5 A |
| Voltage |
750 V |
| impulse voltage |
2 kV |
| MECHANICAL CHARACTERISTICS |
| Screw |
M3 |
| Recommended torque |
0.5÷0.55 Nm / 4.5÷4.9 in.lbs |
| APPROVALS DATA |
|
 |
 |
|
|
EN 60998-1 | | UL 1059 |
|
Current |
13.5 A |
- |
13.5 A factory / 10 A field |
| Voltage |
750 V |
- |
600 V |
| Wire section |
1.5 mm² |
- |
16 AWG |
|
Torque |
0.5 Nm |
- |
4.5 Lb-in |
|
FILE |
EQ202 |
- |
E178356 |
| MATERIALS |
| Housing |
PA - UL 94 V0 |
| Screw |
Galvanized steel |
| Clamp | Nickel-plated copper alloy |
| Terminal |
Tin-plated copper alloy |
| SCIP Number | 8e28a064-07ab-45c1-afc0-7873209ceda4 |
| COLOURS |
|
Standard |
On request |
|
|
 |
| POLES | NAME | 3D FILE | | 2 | MV152-10,16-V-L | File not available for this product | | 3 | MV153-10,16-V-L | File not available for this product | | 4 | MV154-10,16-V-L | File not available for this product | | 5 | MV155-10,16-V-L | File not available for this product | | 6 | MV156-10,16-V-L | File not available for this product |
|
| DIMENSIONAL IMAGE |
 |
