PCR__-5,08-V

PDF
Crimp male plug-in connector - Stackable version - Pitch 5,08mm - 02÷08/11 poles
PCR___5_08_V4
GENERAL INFORMATION
pitch 5,08 mm
Height 19.2 mm
Depth 6.5 mm
Dimensional class n/a
Wire section -
Clamp opening size -
Wire stripping -
Operating temperature -40 ÷ +130 °C
ELECTRICAL CHARACTERISTICS
Current 4 A
Voltage 250 V
impulse voltage 2 kV
MECHANICAL CHARACTERISTICS
Screw -
Recommended torque -
APPROVALS DATA
Current - - -
Voltage - - -
Wire section - - -
Torque - - -
FILE - - -
MATERIALS
Housing -
Screw -
Clamp-
Terminal -
COLOURS
Standard On request
POLESNAME3D FILE
02PCR02-5,08-VFile not available for this product
03PCR03-5,08-VFile not available for this product
04PCR04-5,08-VFile not available for this product
05PCR05-5,08-VFile not available for this product
06PCR06-5,08-VFile not available for this product
07PCR07-5,08-VFile not available for this product
08PCR08-5,08-VFile not available for this product
11PCR11-5,08-VFile not available for this product
DIMENSIONAL IMAGE
