GENERAL INFORMATION
Pitch	5 mm
Height	15 mm
Depth	9.5 mm
Dimensional class	Media
Wire section	2.5 mm² / 14 AWG
Clamp opening size	2.7 x 2.7 mm
Wire stripping	max 7 mm
Operating temperature	-40 ÷ +130 °C

ELECTRICAL CHARACTERISTICS
Current	16 A
Voltage	250 V
Test voltage	-

MECHANICAL CHARACTERISTICS
Screw Type	M3 - Captive
Recommended torque	0.5÷0.55 Nm / 4.5÷4.9 in.lbs

APPROVALS DATA
Current	16 A	-	15 A factory / 15 A field
Voltage	250 V	-	300 V
Wire section	2.5 mm²	-	14 ÷ 30 AWG
Torque	0.5 Nm	-	4.5 Lb-in
FILE	CA02.01614	-	E178356

MATERIALS
Housing	PA - UL 94 V0
Screw	Galvanized steel
Clamp	Nickel-plated copper alloy
Terminal	Tin-plated copper alloy
Scip Number	-

COLOURS
Standard	On request
